ISO 13485:2016 7.3: Medical device design controls and why they’re important

Aaron Hoare Date published: Oct 17, 23

Medical device design controls are a set of policies and practices intended to ensure consistent translation of input requirements into a physical product that meets those requirements.
Good design controls are important to:

• Reduce product risks
• Demonstrate your product is fit for purpose
• Align your organization

ISO 13485:2016 sets out a series of requirements for design controls. So how can you actually apply, manage and use our software to ensure you are compliant with ISO 13485 design control requirements?

Each of the sub-clauses in 7.3 require documented SOPs (Standard Operating Procedures). Our software takes this one step further – it enables you to enforce each of the procedures, making quality by design and default.

It's a much more natural way to plan, record and manage quality - an approach preferred by auditors. Rather than SOPs which are bolted-on, they are embedded. Quality is part of the culture. It's no longer a "quality management system" as such, it's the business management system.

This is how businesses are achieving ISO standards like ISO 13485 without even one minor non-conformity. Everything is considered throughout, there is full traceability – nothing can be missed.

The examples below demonstrate our software solutions and ISO 13485 design control in practice.

Looking for a useful resource to help you manage your compliance with ISO 13485? Download our comprehensive compliance checklist now, which takes you through the key checks you need to make to meet every clause in ISO 13485.

Download now

7.3.1 General: Prepare procedures for design and development:

Ideagen Quality Management’s document module allows you to prepare procedures for design and development. The system also automatically generates and sends notifications via users personal To-Do-List and Email. To-Do List notifications contain a link direct to the relevant document and, where required, a tick box to acknowledge 'read and understood'. The system provides full visibility into who has confirmed a 'read and understood' receipt of new or changed documents and highlights outstanding user actions via both the KPI Dashboard and standard reports.

7.3.2 Design and development planning:

The documents module enables you to:

• Plan and control product design and development.
• Document needed resources
• Retain and maintain planning documents.
• Document the design and development stages.
• Document responsibilities and authorities for design and development.
• Document the methods to ensure traceability of outputs.

In the design and development planning phase, you also need to identify user needs, conduct a preliminary risk assessment and put together your risk management plan. The risk module stores risk information in a central, searchable database repository. Users may define as many classifications for risk likelihood, risk categories, risk types etc. as required for inclusion in risk templates for different types of risk. Risks in the risk manager can even be associated with documentation controlled in the document manager, so any changes can be easily managed at a later date.

Document review dates can also be scheduled in the system and records associated with the reviews. Ideagen QMS also features a training module which enables you to manage and control the competence resources needed for the project. This allows you to make sure all the relevant personnel have the right training and competencies.

7.3.3 Design and development inputs:

Once the user needs have been established, you need to establish your design and development inputs. The documents module enables you to retain all records of this happening, such as:

• Device description
• Usability requirements
• Substantial equivalence comparison
• Software
• Labelling
• Target product profile

7.3.4 Design and development outputs:

Any combination of Ideagen’s quality management software modules can be used to:

• Ensure design and development outputs meet input requirements. Provide appropriate information or purchasing, production and service.
• Ensure design and development outputs contain or reference product acceptance criteria.
• Ensure design and development outputs specify the characteristics of the product that are essential for its safe and proper use.
• Ensure design and development outputs are in a form suitable for verification and against inputs.
• Ensure design and development outputs approved prior to release.
• Retain records of design and development outputs.

7.3.5 Design and development review:

Design and development review requires you to define the requirements and process of collecting peer input at various points in the development process. In the documents module, the system can enforce a defined approval workflow. Only when the workflow has been completed, with all required approvals given, will the document be automatically published and made available to authorized users.

If approval is rejected then the document will not be published but will be retained, with restricted access, for information and the document owner notified. The rejected document must be deleted before a replacement can be uploaded.

Document Manager also enables you to:

• Perform systematic reviews of design and development at suitable stages.
• Evaluate the ability of the results to meet requirements.
• Propose necessary actions.
• Ensure that representatives of functions concerned with the stages being reviewed are participating in these reviews.
• Retain records of the results of the reviews and necessary actions.

7.3.6 Design and development verification:

Design verification proves the medical device has been designed correctly.

In the audits module of Ideagen QMS, authorized users are able to schedule audits. Records of audits and inspections, together with details of corrective and preventative actions and any supporting information is held in a central, searchable repository. Users are able to create template action types to categorize particular types of response.

The system also enables you to:

• Perform design and development verification in accordance with planned and documented arrangements.
• Document verification plans.
• Include in the verification the confirmation that the design outputs meet design outputs when connected or interfaced.

Retain records of the results and conclusions of the verification and necessary actions.

If you want a more in-depth explanation of the requirements set out in ISO 13485, download our ISO 13485 whitepaper, to learn what key parts of the standard will mean for your medical device setting in practice.

Download now

7.3.7 Design and development validation:

Design validation is about proving you designed the correct medical device. Any issues can be raised in CAPA Manager. The super users are able to tailor the issue recording forms and template workflows for different types of event to ensure they are managed appropriately.

Again, Audit Manager and Document Manager can be used to:

• Perform design and development validation in accordance with planned and documented arrangements.
• Document validation plans.
• Conduct design validation on representative product.
• Record the rationale for the choice of product used for validation.
• Perform clinical evaluations or performance evaluations of the medical device as part of design and development validation in accordance with applicable regulatory requirements.
• Include in the validation confirmation that the requirements for the specified application or intended use have been met when so connected or interfaced.
• Complete validation prior to release for use of product to the customer.

Retain records of the results and conclusion of validation and necessary actions.

7.3.8 Design and development transfer:

The documents module enables you to document a procedure for transferring design and development outputs to manufacturing. You must record results and conclusions of the transfer. The equipment module enables you to maintain a repository of equipment assets, associate any processes and procedures with equipment records, and demonstrate that the production capability can meet the product requirements.

7.3.9 Control and design development changes:

CAPA Manager enables you to manage the documented procedures to control design and development changes. Dynamic forms enable you to customize the response based on the determined significance of change. All documents, audits, equipment, supplier histories, can be associated with the changes to ensure proper control for reviewing, verifying, validating, approving, and retaining records of changes.

7.3.10 Design and development files:

The system has a flexible architecture which makes it easy to maintain a design and development file for each medical device type or family. Include or reference in this file records generated to demonstrate satisfaction to design and development requirements. Include or reference in this file records for design and development changes.

Use quality management software to meet ISO 13485 requirements

Ideagen offer software solutions to help your medical device organization with all its ISO 13485 needs. Ensure patient safety, customer satisfaction, and unbreakable standards of quality by using Ideagen Quality Management. We are trusted across the globe to offer tailored solutions to organizations across the life sciences to make compliance with key regulations simple. Among those organizations is counter a number of medical device organizations.

Find out how one of our medical device customers used our software to manage their medical device design controls and comply with ISO 13485 and other regulatory requirements.

Discover how Ideagen Quality management can be used to meet each clause within ISO 13485 by downloading our Ideagen QMS for ISO 13485 guide.

Read now
